Hardware

All vacuum systems require connections for items like gauges, valves and pumps. Select hardware that makes connecting your high system or integration easy and clean. The simpler your connections are, the less chance there is for a vacuum leak. While these connections have to preserve vacuum integrity, they also have to be modular to allow flexibility and simplicity. All hardware is new and contamination free.
HW-01
WING – NUT CLAMP

Part Number: NW16CW
Price: $5.25

Part Number: NW25CW
Price: $7.00

Part Number: NW40CW
Price: $8.25

Part Number: NW63CW
Price: $25.00

Part Number: NW100CW
Price: $35.00

Part Number: NW160CW
Price: $40.00

Part Number: NW200CW
Price: $45.00

HW-02
CENTERING RING ASSEMBLY SS-VITON & CENTERING RING ASSEMBLY W/ SPLINTER SHIELD

Part Number: NW16075SRV
Price: $5.50

Part Number: NW25100SRV
Price: $7.00

Part Number: NW40100SRV
Price: $9.25

Part Number: NW63250SRV
Price: $45.00

Part Number: NW100400SRV
Price: $58.00

Part Number: NW160600SRV
Price: $74.00

Part Number: NW200800SRV
Price: $100.00

Part Number: NW2501000SRV
Price: $120.00

Part Number: ISO63CRSS
Price: $250.00

Part Number: ISO100CRSS
Price: $300.00

Part Number: ISO160CRSS
Price: $380.00

Part Number: ISO200CRSS
Price: $540.00

Part Number: ISO250CRSS
Price: $650.00

Part Number: ISO320CRSS
Price: $1600.00

HW-03
NW TO PIPE ADAPTOR

Part Number: NW16X12NPT
Price: $43.00

Part Number: NW16X25NPT
Price: $45.00

Part Number: NW25X12NPT
Price: $43.00

Part Number: NW25X25NPT
Price: $47.00

Part Number: NW25X50NPT
Price: $50.00

Part Number: NW25X75NPT
Price: $67.00

Part Number: NW25X100NPT
Price: $83.00

Part Number: NW40X12NPT
Price: $46.00

Part Number: NW40X25NPT
Price: $49.00

Part Number: NW40X50NPT
Price: $53.00

Part Number: NW40X75NPT
Price: $70.00

Part Number: NW40X100NPT
Price: $85.00

Part Number: NW40X125NPT
Price: $95.00

Part Number: NW40X150NPT
Price: $95.00

HW-09
MISC. INLET FLANGE ADAPTORS / REDUCERS

Part Number: ISO63XISO100CR
Price: $200.00

Part Number: ISO63XISO160CR
Price: $270.00

Part Number: ISO100XISO160CR
Price: $360.00

Part Number: NW40XISO63
Price: $125.00

Part Number: NW40XISO100
Price: $175.00

Part Number: ISO63XCF450
Price: $170.00

Part Number: ISO63XCF600
Price: $250.00

Part Number: ISO100XCF600
Price: $280.00

Part Number: ISO100XCF450
Price: $250.00

Part Number: ISO160XCF800
Price: $335.00

Part Number: ISO200XCF1000
Price: $480.00

Part Number: NW40XCF450
Price: $115.00

Part Number: CF450XCF600
Price: $375.00

Part Number: CF450XCF800
Price: $384.00

Part Number: CF600XCF800
Price: $390.00

Part Number: CF600XCF1000
Price: $625.00

Part Number: CF800XCF1000
Price: $655.00

HW-04
NW TEES AND REDUCING TEES

Part Number: NW16X075T
Price: $60.00

Part Number: NW25X100T
Price: $70.00

Part Number: NW40X160T
Price: $85.00

Part Number: NW25X16T
Price: $71.00

Part Number: NW40X16T
Price: $80.00

Part Number: NW40X25T
Price: $90.00

HW-05
CONICAL NW TO NW REDUCER

Part Number: NW25X16CR
Price: $45.00

Part Number: NW40X16CR
Price: $58.00

Part Number: NW40X25CR
Price: $58.00

HW-06
HOSE ADAPTOR ALUMINUM

Part Number: NW1650H
Hose Size: .50
Price: $10.00

Part Number: NW2550H
Hose Size: .50
Price: $16.00

Part Number: NW2575H
Hose Size: .75
Price: $12.00

Part Number: NW40150H
Hose Size: 1.50
Price: $16.00

HW-08
90 DEGREE ELBOW

Part Number: NW16075E90
Price: $38.00

Part Number: NW25100E90
Price: $43.00

Part Number: NW40150E90
Price: $60.00

HW-10
BOLTS, NUTS AND COPPER GASKETS

Part Number: 450-CG
Description: Copper Gasket, 4.5”/CF63
Price: $6.00

Part Number: 450-BK
Description: (25) Bolt, Nut & Washer Kit
Price: $22.00

Part Number: 600-CG
Description: Copper Gasket, 6”/CF100
Price: $9.00

Part Number: 600-BK
Description: (25) Bolt, Nut & Washer Kit
Price: $22.00

Part Number: 800-CG
Description: Copper Gasket, 8”/CF160
Price: $15.00

Part Number: 800-BK
Description: (25) Bolt, Nut & Washer Kit
Price: $27.00

Part Number: 1000-CG
Description: Copper Gasket, 10”/CF200
Price: $18.00

Part Number: 1000-BK
Description: (25) Bolt, Nut & Washer Kit
Price: $29.00

Part Number: 1200-CG
Description: Copper Gasket, 12”/CF250
Price: $45.00

Part Number: 1200-BK
Description: (32) Bolt, Nut & Washer Kit
Price: $48.00

HW-11
METAL FLEX HOSE

Part Number: NW16075MH10
Length: 10”
Price: $95.00

Part Number: NW25100MH10
Length: 10”
Price: $105.00

Part Number: NW40150MH10
Length: 10”
Price: $132.00

Part Number: NW16075MH20
Length: 20”
Price: $140.00

Part Number: NW25100MH20
Length: 20”
Price: $165.00

Part Number: NW40150MH20
Length: 20”
Price: $175.00

Part Number: NW16075MN30
Length: 30”
Price: $185.00

Part Number: NW25100MH30
Length: 30”
Price: $200.00

Part Number: NW40150MH30
Length: 30”
Price: $270.00

Part Number: NW16075MN40
Length: 40”
Price: $235.00

Part Number: NW25100MH40
Length: 40”
Price: $265.00

Part Number: NW40150MH40
Length: 40”
Price: $275.00

Part Number: NW16075MN48
Length: 48”
Price: $249.00

Part Number: NW25100MH48
Length: 48”
Price: $265.00

Part Number: NW40150MH48
Length: 48”
Price: $345.00

HW-12
ISO TO MALE NPT 1/8, 1/4, 1/2, 3/4

Part Number: NW16075AP12
Price: $11.50

Part Number: NW25100AP12
Price: $12.50

Part Number: NW40150AP12
Price: $14.00

Part Number: NW16075AP25
Price: $11.50

Part Number: NW25100AP25
Price: $12.50

Part Number: NW40150AP25
Price: $14.00

Part Number: NW25100SP50
Price: $24.00

Part Number: NW40150SP50
Price: $31.00

Part Number: NW40150SP75
Price: $33.00

HW-20
NW TO QUICK COUPLING

Part Number: NW16Q12
Price: $58.00

Part Number: NW16Q25
Price: $58.00

Part Number: NW16Q38
Price: $64.00

Part Number: NW16Q50
Price: $64.00

Part Number: NW25Q25
Price: $68.00

Part Number: NW25Q38
Price: $68.00

Part Number: NW25Q50
Price: $68.00

Part Number: NW25Q100
Price: $84.00

Part Number: NW40Q25
Price: $73.00

Part Number: NW40Q50
Price: $73.00

Part Number: NW40Q100
Price: $87.00

Part Number: NW40Q150
Price: $159.00

HW-07
BLANK FLANGE

Part Number: NW16SB
Price: $7.00

Part Number: NW25SB
Price: $7.00

Part Number: NW40SB
Price: $55.00

Part Number: NW100SB
Price: $85.00

Part Number: NW160SB
Price: $95.00

Part Number: NW200SB
Price: $175.00

HW-13
TURBO VIBRATION DAMPER

Part Number: VD631SO
Price: $1,265.00

Part Number: VD63CF
Price: $,1615.00

Part Number: VD100ISO
Price: $1,285.00

Part Number: VD100CF
Price: $1,980.00

HW-14
MANUAL VENT VALVE NW16

Part Number: NW16MV
Price: $185.00

HW-15
ROTATABLE ISO-K TO ISO-F ADAPTION

Part Number: ISO 63 BR
Price: $98.00

Part Number: ISO 100 BR
Price: $175.00

Part Number: ISO 160 BR
Price: $295.00

Part Number: ISO 200 BR
Price: $345.00

Part Number: ISO 250 BR
Price: $415.00

HW-16
RIGHT ANGLE MANUAL VALVES

Part Number: NW160752NWB
Description: NW16
Price: $306.00

Part Number: NW251002NWB
Description: NW25
Price: $325.00

Part Number: NW401502NWB
Description: NW40
Price: $350.00

Part Number: ISO632502ISO
Description: ISO63
Price: $650.00

Part Number: CF4502502CF
Description: CF4.5”/63
Price: $650.00

HW-17
HIGH VACUUM BALL VALVE 10-10 TORR

Part Number: NW161075
Description: NW16
Price: $247.00

Part Number: NW251100
Description: NW25
Price: $362.00

Part Number: NW401150
Description: NW40
Price: $443.00

Part Number: NW501200
Description: NW40
Price: $450.00

HW-18
DOUBLE CLAW CLAMP

Part Number: ISO63-1000DC
Price: $7.00

Part Number: ISO160-250DC
Price: $9.00

HW-19
ELECTRONICALLY ACTIVATED SAFETY ISOLATION VALVE DN 16 – 25

Part Number: SIV 16
Description: NW16, 115V
Price: $427.00

Part Number: SIV 25
Description: NW25, 115V
Price: $427.00

fine-regulating-valve
FINE REGULATING VALVE
(10-3 to 10-7 MBAR)

Part Number: EVGW-J4-KF
Description: NW16
Price: $618.00

Part Number: EVGW-J4-CF
Description: CF -1.33″
Price: $618.00
