Edwards Turbo Pumps

The new nEXT turbo pumps were designed to combine all the latest technological advances with two decades of experience based on the tried and trusted EXT/STP turbo pumps. The new nEXT units set the benchmark for performance, reliability, and end user serviceability for a scientific turbo. They are available in four sizes. New technologies employed in the nEXT turbos have enabled the pumps to be serviced by the end user in the field in less than 10 minutes. Choose from a complete line of accessories to make integration easy.
Features
• Multiple drag stage
• Field serviceable bearing
• Permanent magnetic upper bearing
• Built in Drive unit with cable
• Advanced design
• Exceptional pumping speeds and compression ratios
• LED indicator lights

TIC Controller

The TIC (turbo and instrument controller) has been developed to provide the end user full functionality and serial communication with a powerful PC driven program. The system allows the end user /OEM total turbo pump controller and ability to support a new nEXT turbo pump, backing pump, and vacuum gauge or multiple vacuum gauge simultaneously. This truly is a one-box controller for a end users entire vacuum system.
Features
• Universal Turbo Controller
• Backing pump support
• Relay options
• Simple system configuration
• Compact instrument
• Clear, easy to use graphic user interface
• Universal power supply
• Serial communications
• Windows PC Program

TAG Display Unit

For a more economical and simple solution, TAG display units can be utilized with any of the NEXT turbo pumps. They offer on/off operations, ability to display one vacuum sensor, air cooling kit, and vent valve. Power supply is required.
nEXT55-edwards-pump

nEXT55 D

Technical Specifications

Inlet Flange:
NW 40, ISO 63, CF 63
Pumping Speed, L/S (N):
55
Pumping Speed, L/S (He):
41
Pumping Speed, L/S (H):
27
Compression Ratio (N):
1 x 10/11
Compression Ratio (He):
6.9 x 10/5
Compression Ratio (H):
2.9 x 10/4
Ultimate Pressure (mbar):
10-10
Startup Time (sec):
90
Rotational Speed (rpm):
90,000
Orientation:
Vertical / Horizontal
Backing Pressure (mbar):
18
Outlet Flange:
NW 16
Weight (lb):
5.5
Price:
$6,668.00
Controller:
TIC/TAG
Controller Price:
$2,714.00

Ordering Information

Turbo Pump
NW Inlet: B8E-21-0A01
ISO Inlet: BB8E-21-0C01
CF Inlet: B8E-21-0B01

Controller
D397-21-000

Pump Cable (3m)
D397-00-836

Air Cooling
B8G2-00-820

Vent Valve
B580-66-010

Power Cord
D400-13-120

nEXT85

nEXT85 H

Technical Specifications

Inlet Flange:
NW 40, ISO 63, CF 63
Pumping Speed, L/S (N):
84
Pumping Speed, L/S (He):
61
Pumping Speed, L/S (H):
50
Compression Ratio (N):
1 x 10/11
Compression Ratio (He):
4.6 x 10/7
Compression Ratio (H):
6.5 x 10/5
Ultimate Pressure (mbar):
10-10
Startup Time (min):
2
Rotational Speed (rpm):
90,000
Orientation:
Vertical / Horizontal
Backing Pressure (mbar):
< 11
Outlet Flange:
NW 16
Weight (lb):
6.6
Price:
$8,730.00
Controller:
TIC/TAG
Controller Price:
$2,483.00

Ordering Information

Turbo Pump
NW Inlet: B8G4-10-A01
ISO Inlet: B8G4-10-B01
CF Inlet: B8G4-10-C01

Controller
D397-21-000

Pump Cable (3m)
D397-00-836

Air Cooling
B8G2-00-820

Vent Valve
B580-66-010

Power Cord
D400-13-120

edwards-nEXT240D

nEXT240 T

Technical Specifications

Inlet Flange:
ISO 100, CF 100
Pumping Speed, L/S (N):
240
Pumping Speed, L/S (He):
230
Pumping Speed, L/S (H):
165
Compression Ratio (N):
1 x 10/11
Compression Ratio (He):
1 x 10/6
Compression Ratio (H):
1 x 10/4
Ultimate Pressure (mbar):
10-10
Startup Time (min):
2
Rotational Speed (rpm):
60,000
Orientation:
Any
Backing Pressure (mbar):
20
Outlet Flange:
NW 25
Weight (lb):
13
Price:
$10,419.00
Controller:
TIC/TAG
Controller Price:
$2,483.00

Ordering Information

Turbo Pump
ISO Inlet: B813-00-100
CF Inlet: B813-00-200

Controller
D397-21-000

Pump Cable (3m)
N/A

Air Cooling
B580-53-185

Vent Valve
B580-66-010

Power Cord
D400-13-120

edwards-nEXT300D

nEXT300 T

Technical Specifications

Inlet Flange:
ISO 100, CF 100
Pumping Speed, L/S (N):
300
Pumping Speed, L/S (He):
340
Pumping Speed, L/S (H):
280
Compression Ratio (N):
1 x 10/11
Compression Ratio (He):
1 x 10/6
Compression Ratio (H):
1 x 10/5
Ultimate Pressure (mbar):
10-10
Startup Time (min):
2
Rotational Speed (rpm):
60,000
Orientation:
Any
Backing Pressure (mbar):
20
Outlet Flange:
NW 25
Weight (lb):
14
Price:
$11,018.00
Controller:
TIC/TAG
Controller Price:
$2,483.00

Ordering Information

Turbo Pump
ISO Inlet: B823-00-100
CF Inlet: B823-00-200

Controller
D317-21-000

Pump Cable (3m)
N/A

Air Cooling
B580-53-185

Vent Valve
B580-66-010

Power Cord
D400-13-120

edwards-nEXT400D

nEXT400 T

Technical Specifications

Inlet Flange:
ISO 160, CF 160
Pumping Speed, L/S (N):
400
Pumping Speed, L/S (He):
390
Pumping Speed, L/S (H):
325
Compression Ratio (N):
1 x 10/11
Compression Ratio (He):
1 x 10/8
Compression Ratio (H):
5 x 10/6
Ultimate Pressure (mbar):
10-10
Startup Time (min):
2
Rotational Speed (rpm):
60,000
Orientation:
Any
Backing Pressure (mbar):
20
Outlet Flange:
NW 25
Weight (lb):
15
Price:
$12,426.00
Controller:
TIC/TAG
Controller Price:
$2,483.00

Ordering Information

Turbo Pump
ISO Inlet: B833-00-300
CF Inlet: B833-00-400

Controller
D397-21-000

Pump Cable (3m)
N/A

Air Cooling
B580-53-175

Vent Valve
B580-66-010

Power Cord
D400-13-120

nEXT730D

nEXT730 D

Technical Specifications

Inlet Flange:
ISO 160, CF 160
Pumping Speed, L/S (N):
730
Pumping Speed, L/S (He):
820
Pumping Speed, L/S (H):
715
Compression Ratio (N):
10/11
Compression Ratio (He):
1.2 x 10/8
Compression Ratio (H):
4 x 10/6
Ultimate Pressure (mbar):
3x 10-10
Startup Time (min):
2
Rotational Speed (rpm):
49,200
Orientation:
Any
Backing Pressure (mbar):
20
Outlet Flange:
NW 25
Weight (lb):
32
Price:
$16,650.00
Controller:
TIC/TAG
Controller Price:
$2,714.00

Ordering Information

Turbo Pump
ISO Inlet: B8J-200-300
CF Inlet: B8J-200-400

Controller
D397-21-000

Pump Cable (3m)
D395-92-800

Air Cooling
B8J-200-800

Vent Valve
B8G-200-834

Power Cord
B8J-200-813

nEXT730D

nEXT930 D

Technical Specifications

Inlet Flange:
ISO 200, CF 200
Pumping Speed, L/S (N):
925
Pumping Speed, L/S (He):
905
Pumping Speed, L/S (H):
735
Compression Ratio (N):
10/11
Compression Ratio (He):
1.2 x 10/8
Compression Ratio (H):
4 x 10/6
Ultimate Pressure (mbar):
3x 10-10
Startup Time (min):
2
Rotational Speed (rpm):
49,200
Orientation:
Any
Backing Pressure (mbar):
20
Outlet Flange:
NW 25
Weight (lb):
34
Price:
$18,100.00
Controller:
TIC/TAG
Controller Price:
$2,714.00

Ordering Information

Turbo Pump
ISO Inlet: B8K-200-D00
CF Inlet: B8K-200-F00

Controller
D397-21-000

Pump Cable (3m)
D395-92-800

Air Cooling
B8J-200-800

Vent Valve
B8G-200-834

Power Cord
B8J-200-813

nEXT1230-edwards-pump

nEXT1230 H

Technical Specifications

Inlet Flange:
ISO 200, CF 200
Pumping Speed, L/S (N):
1250
Pumping Speed, L/S (He):
1350
Pumping Speed, L/S (H):
1150
Compression Ratio (N):
1 x 10/11
Compression Ratio (He):
4 x 10/8
Compression Ratio (H):
1 x 10/7
Ultimate Pressure (mbar):
10-10
Startup Time (min):
3
Rotational Speed (rpm):
42,000
Orientation:
Inverted
Backing Pressure (mbar):
15
Outlet Flange:
NW 40
Weight (lb):
55
Price:
$23,095.00
Controller:
TIC/TAG
Controller Price:
$2,714.00

Ordering Information

Turbo Pump
ISO Inlet: B8N-4A-0F00
CF Inlet: B8N-4A-0F00

Controller
D397-21-000

Pump Cable (3m)
D397-00-836

Air Cooling
B8J-200-80

Vent Valve
B8G-200-834

Power Cord
B8J-200-830
