Instant Systems

Turbo Vacuum has assembled Instant Systems. A selection of high vacuum pumping stations that are proven, tested, oil-free, air cooled, multifunctional, and ready to use. Choose a complete plug-and-play system that can be integrated into any application where simple ultra clean high vacuum is needed. Applications include: backing larger turbo pumps, chamber evacuations, instrumentation, research and development.
Features
• Complete Integrated System
• Maximum Reliability
• Compact
• High Pumping Speeds & Gas throughputs
• Global World Voltage Acceptable
• Oil Free
• RS232 Analog Communication
• Vacuum Gauge LED Screen Compatible
• Economical
IS11

IS11

Technical Specifications

Inlet Flange:
NW 25
Pumping Speed, L/S (N):
11
Pumping Speed, L/S (He):
6
Pumping Speed, L/S (H):
3.7
Compression Ratio (N):
3 x 10/6
Compression Ratio (He):
3 x 10/3
Compression Ratio (H):
3 x 10/2
Ultimate Pressure (mbar):
10-6
Backing Pump (CFM):
0.7 PTFE
Price:
$6,900.00

Ordering Information

Instant Systems
NW: V010113
ISO: N/A
CF: N/A

IS60

IS60

Technical Specifications

Inlet Flange:
NW 40, ISO 63, CF 63
Pumping Speed, L/S (N):
60
Pumping Speed, L/S (He):
55
Pumping Speed, L/S (H):
22
Compression Ratio (N):
N/A
Compression Ratio (He):
N/A
Compression Ratio (H):
N/A
Ultimate Pressure (mbar):
10-9
Backing Pump (CFM):
0.7 PTFE
Price:
$6,900.00

Ordering Information

Instant Systems
NW: V120816
ISO: V120815
CF: V120814

IS60-N952

IS60 N952

Technical Specifications

Inlet Flange:
NW 40, ISO 63, CF 63
Pumping Speed, L/S (N):
60
Pumping Speed, L/S (He):
55
Pumping Speed, L/S (H):
22
Compression Ratio (N):
N/A
Compression Ratio (He):
N/A
Compression Ratio (H):
N/A
Ultimate Pressure (mbar):
10-9
Backing Pump (CFM):
1.2
Price:
$7,200.00

Ordering Information

Instant Systems
NW: V072321
ISO: V072322
CF: V072323

IS240

IS240

Technical Specifications

Inlet Flange:
ISO 100, CF 100
Pumping Speed, L/S (N):
240
Pumping Speed, L/S (He):
55
Pumping Speed, L/S (H2):
160
Compression Ratio (N):
N/A
Compression Ratio (N2):
1 x 10/8
Compression Ratio (H2):
4 x 10/4
Ultimate Pressure (mbar):
10-9
Backing Pump (CFM):
1.2
Price:
$8,900.00

Ordering Information

Instant Systems
NW: V072321
ISO: V07234
CF: V07235

Turbolab-Core-90i

TLC90i

Technical Specifications

Inlet Flange:
NW 40, ISO 63, CF 63
Pumping Speed, L/S (N):
90
Pumping Speed, L/S (He):
90
Pumping Speed, L/S (H):
78
Compression Ratio (N):
10/11
Compression Ratio (He):
N/A
Compression Ratio (H):
10/7
Ultimate Pressure (mbar):
10-10
Backing Pump (CFM):
0.77
Price:
$7,871.00

Ordering Information

Instant Systems
NW: TLC9040
ISO: TLC90ISO
CF: TLC90CF

Turbolab-Core-250i

TLC250i

Technical Specifications

Inlet Flange:
ISO 100, CF 100
Pumping Speed, L/S (N):
225
Pumping Speed, L/S (He):
250
Pumping Speed, L/S (H):
210
Compression Ratio (N):
10/11
Compression Ratio (He):
10/8
Compression Ratio (H):
10/7
Ultimate Pressure (mbar):
10-10
Backing Pump (CFM):
0.77
Price:
$11,244.00

Ordering Information

Instant Systems
NW: N/A
ISO: TLC250ISO
CF: TLC250CF

TL 350

TL350

Technical Specifications

Inlet Flange:
ISO 100, CF 100
Pumping Speed, L/S (N):
290
Pumping Speed, L/S (He):
360
Pumping Speed, L/S (H):
350
Compression Ratio (N):
10/11
Compression Ratio (He):
10/8
Compression Ratio (H):
10/6
Ultimate Pressure (mbar):
10-9
Backing Pump (CFM):
0.5
Price:
$11,190.00

Ordering Information

Instant Systems
NW: N/A
ISO: TL350ISO
CF: TL350CF

hc-80-neo

HC 80 Neo

Technical Specifications

Inlet Flange:
NW 40, ISO 63, CF 63
Pumping Speed, L/S (N):
67
Pumping Speed, L/S (He):
58
Pumping Speed, L/S (H):
48
Compression Ratio (N):
1 x 10/11
Compression Ratio (He):
1.3 x 10/7
Compression Ratio (H):
1 x 10/5
Ultimate Pressure (mbar):
10-8
Backing Pump (CFM):
0.59
Price:
$9,060.00

Ordering Information

Instant Systems
NW: HC80NEOKF
ISO: HC80NEOISO
CF: HC80NEOCF

hc-300-neo

HC 300 Neo

Technical Specifications

Inlet Flange:
ISO 100, CF 100
Pumping Speed, L/S (N):
260
Pumping Speed, L/S (He):
255
Pumping Speed, L/S (H):
220
Compression Ratio (N):
1 x 10/11
Compression Ratio (He):
2 x 10/8
Compression Ratio (H):
3 x 10/5
Ultimate Pressure (mbar):
10-7
Backing Pump (CFM):
0.59
Price:
$17,200.00

Ordering Information

Instant Systems
ISO: HC300NEOISO
CF: HC300NEOCF

IS-TS75D

TS85D

Technical Specifications

Inlet Flange:
NW 40, ISO 63, CF 63
Pumping Speed, L/S (N):
84
Pumping Speed, L/S (He):
57
Pumping Speed, L/S (H):
53
Compression Ratio (N):
N/A
Compression Ratio (He):
N/A
Compression Ratio (H):
N/A
Ultimate Pressure (mbar):
10-8
Backing Pump (CFM):
0.7
Price:
$7,850.00

Ordering Information

Instant Systems
NW: TS85D40
ISO: TS85DISO
CF: TS85DCF

ts300d

TS300D

Technical Specifications

Inlet Flange:
ISO 100, CF 100
Pumping Speed, L/S (N):
300
Pumping Speed, L/S (He):
N/A
Pumping Speed, L/S (H):
N/A
Compression Ratio (N):
1 x 10/11
Compression Ratio (He):
N/A
Compression Ratio (H):
N/A
Ultimate Pressure (mbar):
10-10
Backing Pump (CFM):
0.7
Price:
$14,440.00

Ordering Information

Instant Systems
ISO: TS300DISO
CF: TS300DCF

FJ-80

FJ-80

Technical Specifications

Inlet Flange:
ISO 63, CF 63
Pumping Speed, L/S (N):
62
Pumping Speed, L/S (He):
N/A
Pumping Speed, L/S (H):
N/A
Compression Ratio (N):
2 x 10/6
Compression Ratio (He):
N/A
Compression Ratio (H):
4 x 10/3
Ultimate Pressure (mbar):
10-8
Backing Pump (CFM):
0.7
Price:
$6,900.00

Ordering Information

Instant Systems
ISO: FJ-80-ISO
CF: FJ-80-CF
